Main Features
3K Resolution
πLink Multi-Channel System
Mini and Versatile
24/7 Parking Monitoring
Ultra-Reliable & Rock-Solid Build
Wi-Fi Turbo Lightning-Fast Transmission
Imaging Powerhouse
Ultimate 3K Imaging
Grab Every Detail
With over a decade of imaging expertise, DDPAI RANGER M1, motorcycle-dashcam-industry-leading 3K@30fps video quality. The 145° wide-angle lens provides clear and comprehensive road views, enhancing your ride’s safety.
30fps
High Resolution
145°
Wide-Angle Lens
Ultra-Large F1.55 Aperture
Crystal Clear Night Vision
The F1.55 aperture allows more light in, ensuring sharp images even during nighttime rides.
Six High-Definition, High-Transparency Optical Lenses
Ultra-Large F1.55 Aperture increases light intake by 67% more than F2.0
*Data from DDPAI Lab
Advanced Stabilization Algorithm for Smooth Footage
Supports one-click stabilization to keep your footage steady on rough roads. Important details remain clear even during bumps or collisions.
SR4.0-Lite Effect
The built-in six-axis gyroscope generates acceleration and lean data. AI algorithms add dynamic effects to your videos, making your rides more engaging and shareable.
πLink Multi-channel System
More Coverage
DDPAI’s πLink technology enables two RANGER M1 cameras to wirelessly connect for 3K HD dual recording, providing wider coverage. You can also easily manage different views and access preview, playback, and settings directly from the DDPAI app.
All-Day Recording with Battery Connection
1CH Power Mode
*Supports direct power from the motorcycle battery via USB-A or Intelligent hardwire kit.
2CH Power Mode
*Powered via intelligent hardwire kit connected to the motorcycle's battery.
Starts recording automatically when the motorcycle is turned on.
*Requires a battery voltage of 11.8V or above.
Sleek Design
Perfect Fit for Your Motorcycle
With a rock gray color and golden ratio dimensions, the RANGER M1 seamlessly integrates with your motorcycle.
Built to Last
Waterproof, Dustproof, Drop-Resistant
Engineered for extreme durability, the RANGER M1 features IP67 protection, ensuring reliable recording in any circumstance, be it rain, snow, or desert dust.
Shockproof & Drop-Resistant
Wi-Fi Turbo Lightning-fast Transmission
High Speed, Zero Lag
Powered by DDPAI’s Wi-Fi Turbo technology, the M1’s 5GHz Wi-Fi dramatically boosts video transfer speeds, enabling seamless playback and lightning-fast downloads.
23S
Download a 300MB Video
75%
Speed Improvement
*Date from DDPAI Lab
Fast Bluetooth Connection
Effortless Operation
After the initial pairing, the RANGER M1 quickly connects to the DDPAI app via Bluetooth without requiring a password, ensuring stable and fast connectivity.
Worry-Free Automatic Loop Recording
The RANGER M1 starts recording as soon as you start your motorcycle, with loop recording that automatically overwrites the previous footage when the memory card is full. Supports up to 256GB microSD card.
20h
of continuous 3K recording.
Low-power Parking Monitoring 24/7 Protection for Your Motorcycle
The RANGER M1 will capture emergency images and record a 30-second video when a collision is detected by G-sensor while the motorcycle is parked. If no further collisions occur within 30 seconds, it switches to low-energy sleep mode. Enjoy peace of mind even when you’re away from your motorcycle.
*In the event of continuous collisions, the M1 can record for up to 2 minutes.
Fall Detection Capture Key Evidence Locked
*Supports 10s, 20s, or 30s videos, adjustable in the DDPAI app
Add-ons
Intelligent Hardwire Kit
What's in the box
M1 1CH Set
RANGER M1
3M Adhesive Mount (with Three Prongs)
Bolt
Mount Fixing Screw*4
Bolt Fixing Spanner
Anti-theft Spanner for Mount
Anti-theft Spanner for MicroSD Card Cover
Power Cable
Zip Tie*5
3M Adhesive
User Guide
M1 2CH Set
RANGER M1*2
3M Adhesive Mount (with Three Prong)*2
Bolt*2
Mount Fixing Screw*8
Bolt Fixing Spanner
Anti-theft Spanner for Mount
Anti-theft Spanner for MicroSD Card Cover
Intelligent Hardwire Kit
Zip Tie*5
3M Adhesive*2
User Guide
Specification
Model
RANGER M1
Dimensions
63*30.5*29.6mm
Weight
91g
Resolution
3K: 2880x1620@30fps / 2K: 2560x1440@30fps
Lens
Aperture: F1.55 / FOV: 145°
Power Supply
USB-A / Intelligent Hardwire Kit
Battery
80mAh Super Lithium Battery
(Recording protection activates in case of sudden power loss)
Waterproof/Dustproof Rating
IP67
Working Temperature
-20°C~45°C
Stabilization
Stabilization technology by app
Memory Card
MicroSD card (up to 256GB)
Bluetooth
BLE 5.4
Wi-Fi
5GHz Wi-Fi with Wi-Fi Turbo Technology
G-Sensor
Six-axis Gyroscope
